Zeiss OPMI Lumera Surgical Microscope

Contact us for Price & Availability Request a Quote (888) 781-4458

The Zeiss OPMI LUMERA is a great surgical microscope for optics and illumination for cataract and retina surgery. The LUMERA features BightFLex LED illumination technology and apochromatic optics that provide exceptional view and outstanding resolution. BrightFlex is a variable electronic LED that delivers improved red reflux for more confidence in cataract surgery. This microscope delivers excellent clarity and detail all while reducing the amount of light exposure for your patient. Optionally, the LUMERA can feature a fully independent assistant’s microscope that requires no light from the main microscope.

With Stereo Coaxial Illumination (SCI), OPMI Lumera® incorporates a revolutionary illumination technology for the red reflex. Contours are better visible, and you can see details of the ocular anatomy that you have never seen before. With this illumination technology, very little light is required to generate the red reflex. This means less stress for the patient’s eye.

OPMI Lumera adjusts to your needs, not the other way around. The surgical microscope’s touch screen controls both, the microscope head and the video camera. The display is intuitively operated and can be easily accessed.

For freedom of movement – even when OR space is scarce. Combined with the compact suspension system, OPMI Lumera is also good for smaller operating rooms such as those in ambulatory surgery centers.

It’s time to give you and your team more free space in the OR. Experience the new dimension of freedom with no annoying cables and free positioning in your OR. The ergonomically designed foot control panel (FCP and FCP WL) allows you to control your surgical microscope – intuitively and reliably. You can configure the buttons according to your personal requirements. Additionally, to our wireless version, we also offer a wired foot control panel.


  • Pre-Owned
Features Specifications Financing
  • Hassle-free design.
  • BrightFlex illumination.
  • Reduced light exposure for your patients.
  • Apochromatic optics.
  • Focus Range: 48 mm
  • Objective Lens: f = 200 mm
  • Wide-Angle Eyepiece: 12.5x
  • Floorstand: S200

Surgical Microscope

  • Apochromatic optics
  • Motorized zoom system, 1:6 zoom ratio
  • DeepView: depth of field management system
  • Illumination

  • Stereo Coaxial Illumination (SCI): red reflex illumination and surrounding field illumination, both are adjustable, patent pending
  • Light source

  • Halogen light source with fully automatic lamp change in case of lamp failure
  • Integrated 408 mm UV barrier filter
  • Blue blocking filter
  • Retinal protection device
  • Fiber optic illumination
  • Optional: fluorescence filter
  • X-Y coupling

  • 61 mm x 61 mm adjustment range
  • Reset-Button for X-Y coupling, focus and zoom
  • Suspension system

  • Floor stand
  • Maximum load capacity: 14 kg (complete microscope equipment, including accessories)
