Zeiss OPMI 1FC Microscope

Contact us for Price & Availability Request a Quote (888) 781-4458

OPMI® 1-FC microscope from ZEISS symbolizes quality, precision and reliability. By helping define the field of microsurgery, the system has built its own legacy.

The manual system is easy to use and delivers high-fidelity images with the legendary ZEISS optics. The precise fine ideal focus functionality and the brightness adjustment knob allow the surgeon to quickly and easily attain the ideal focus and illumination levels – in routine examinations and surgical procedures.

After completing the procedure, the system can be conveniently moved away from the operating field and automatically shut off by raising the surgical microscope arm upward into the stand-by position.

Available:

  • Pre-Owned
Features Specifications Financing
    The Zeiss OPMI 1FC Microscope features include:

  • Space-saving surgical microscope for routine ENT applications
  • OPMI® 1-FC from ZEISS symbolizes quality, precision and reliability. By helping define the field of microsurgery, the system has built its own legacy.
  • The manual system is easy to use and delivers high-fidelity images with the legendary ZEISS optics. The precise fine ideal focus functionality and the brightness adjustment knob allow the surgeon to quickly and easily attain the ideal focus and illumination levels – in routine examinations and surgical procedures.
  • After completing the procedure, the system can be conveniently moved away from the operating field and automatically shut off by raising the surgical microscope arm upward into the stand-by position.
  • System Illumination
  • System illumination is automatically activated or shut off when moved into the working or stand-by position, respectively.
  • Drapes with ZEISS VisionGuard Lens
  • Surgical Drapes from ZEISS are manufactured with VisionGuard® from ZEISS, a unique, optical lens that works with the surgical microscope’s objective like a single optical unit to ensure optical clarity. The lens can be replaced with a new sterile lens during surgery without compromising sterility.

S100 / OPMI 1-FC
Magnification

  • Manual ZEISS magnification changer, 1:6 ratio in 5 steps
  • Focusing system

  • Manual, using the focus adjusting knob, focusing range: 40 mm
  • Objective lenses

  • Different focal lengths from f = 200 mm to f= 400 mm, graded in steps of 50 mm
  • Tubes / Eyepieces

  • Straight tube, f = 170 mm
  • 45° Inclined tube, f = 170 mm (optional), 10x or optional 12.5x widefield eyepieces
  • Illumination

  • Coaxial illumination, 100W halogen lamp, backup lamp in fast-action lamp changer
  • Rated voltage

  • 115V / 230V
  • Rated frequency

  • 50 Hz – 60 Hz
  • Weight

  • S100 floor stand: approx. 90 kg (with OPMI)
  • S100 wall mount: approx. 45 kg (with OPMI)
  • S100 ceiling mount: approx. 55 kg (with OPMI)
