Marco AFC-330 Automated Fundus Camera
The latest in retinal imaging technology, the AFC-330 breaks new ground in fundus photography with emphasis on capturing the perfect picture every time, regardless of operator experience or skill level. The AFC-330 sets a new standard in speed, automation, and accuracy – achieved with X-Y-Z auto alignment, auto image capture, auto stitch panoramic images, custom-field imaging, auto pairs for stereo-photography, and external photography. Low flash intensity, whisper operation, and auto small pupil mode all facilitate capture. Internal PC and NAVIS-EX SW provide data management.
FEATURES:
8.4" Tilt Touchscreen: The large color touchscreen on the AFC-330 places all functions at the operator’s fingertips with intuitive menus and icons. Exam type, patient selection, database edits, and image review are all possible on the AFC-330’s screen.
Latest Imaging Technology: The AFC-330 delivers unsurpassed ease of use with advanced features that enhance the management of retinal disease, such as glaucoma and diabetic retinopathy.
User Friendly Features: Speed, automation, and accuracy – achieved with X-Y-Z auto alignment, auto image capture, auto stitch panoramic images, custom-field imaging, auto pairs, and external photography.
All-In-One Design: The integrated high-resolution imaging sensor and internal PC eliminates complicated cabling, allowing the AFC-330 to communicate via LAN without the need for an external PC in the screening area, thereby maximizing office space.
Flexible Data: A stand-alone device with USB 2.0 storage media and printer, LAN connection with JPEG and XML output, and integrates with NAVIS-EX software
Technical Details
Type | Non-mydriatic Automated Fundus Camera |
---|---|
Angle of View | 45º (33º in small-pupil photography mode) |
Working Distance | 45.7mm (from objective lens to cornea) |
Minimum Pupil Diameter | 4.0mm (3.3mm in small-pupil photography mode) |
Dioptric Compensation | -33 to +35 D total for patient’s eyes -33 to -7 D with minus dioptric lens -12 to +15 D with no dioptric lens +11 to +35 D with plus dioptric lens |
Focusing Method | Infrared focus split alignment Adjustable range: -12 to +15 D |
Light Source | For observation: Halogen lamp 12V 50W For Photography: Xenon flash lamp 300W |
Flash Intensity | 17 levels from F1 (F4.0 +0.8 EV) to F17 (F16 +0.8 EV) 0.5 EV increments |
Internal Fixation Target | LED (maximum 9 points) |
External Fixation Target | Free-arm (optional) |
Horizontal Movement | 40mm (back and forth) 85mm (left and right) |
Vertical Movement | 32mm |
Chinrest Movement | 62mm (up and down, motorized) |
AutoTrack | X-Y-Z direction |
Auto Capture | Automatic image capture |
Camera | Built-in 12 megapixel CCD camera |
Display | Tiltable 8.4-inch color LCD touchscreen |
Interface | LAN, USB 2.0 |
Measurements | 316mm (W) x 518mm (D) x 579mm (H) 12.4” (W) x 20.4” (D) x 22.8” (H) |
Mass (Approximate) | 29 kg |
Power Supply | AC 100-240 V ±10%, 50 / 60 Hz |
Power Consumption | 150 VA |
